Brandon Checketts

Starting next month, any requests to the Amazon Product Advertising API need to be cryptographically signed. Amazon has given about three months notice and the deadline is quickly approaching. I use the Amazon web services on several sites and came up a fairly generic way to convert an existing URL to a signed URL. I’ve tested with several sites and a variety of functions, and this is working well for me so far:

function signAmazonUrl($url)
{
    global $CONFIG;
    $original_url = $url;

    // Decode anything already encoded
    $url = urldecode($url);

    // Parse the URL into $urlparts
    $urlparts       = parse_url($url);

    // Build $params with each name/value pair
    foreach (split('&', $urlparts['query']) as $part) {
        if (strpos($part, '=')) {
            list($name, $value) = split('=', $part, 2);
        } else {
            $name = $part;
            $value = '';
        }
        $params[$name] = $value;
    }

    // Include a timestamp if none was provided
    if (empty($params['Timestamp'])) {
        $params['Timestamp'] = gmdate('Y-m-d\TH:i:s\Z');
    }

    // Sort the array by key
    ksort($params);

    // Build the canonical query string
    $canonical       = '';
    foreach ($params as $key => $val) {
        $canonical  .= "$key=".rawurlencode($val)."&";
    }
    // Remove the trailing ampersand
    $canonical       = preg_replace("/&$/", '', $canonical);

    // Some common replacements and ones that Amazon specifically mentions
    $canonical       = str_replace(array(' ', '+', ',', ';'), array('%20', '%20', urlencode(','), urlencode(':')), $canonical);

    // Build the si
    $string_to_sign             = "GET\n{$urlparts['host']}\n{$urlparts['path']}\n$canonical";
    // Calculate our actual signature and base64 encode it
    $signature            = base64_encode(hash_hmac('sha256', $string_to_sign, $CONFIG['AMAZON_SECRET_KEY'], true));

    // Finally re-build the URL with the proper string and include the Signature
    $url = "{$urlparts['scheme']}://{$urlparts['host']}{$urlparts['path']}?$canonical&Signature=".rawurlencode($signature);
    return $url;
}

To use it, just set the global variable $CONFIG['AMAZON_SECRET_KEY'] with your Amazon secret key. Then call signAmazonUrl() in any place that you currently have an Amazon API URL.

Like most all of the variations of this, it does require the hash functions be installed to use the hash_hmac() function. That function is generally available in PHP 5.1+. Older versions will need to install it with Pecl. I tried using a couple of versions that try to create the Hash in pure PHP code, but none worked and installing it via Pecl was pretty simple.

I’m graphing a few things around my home and wanted to graph the current outdoor temperature. I wrote this quick script to grab the current temperature or my zip code from weatherunderground.com and have it graphed with MRTG:

#!/usr/bin/php
<?php

$zipcode = $argv[1];
$page = file_get_contents("http://www.wunderground.com/cgi-bin/findweather/getForecast?query=$zipcode&wuSelect=WEATHER");

$current_temp = 0;
if (preg_match('#pwsvariable="tempf" english="&deg;F" metric="&deg;C" value="([0-9\.]+)">#', $page, $matches)) {
    $current_temp = $matches[1];
}

if (preg_match('#Heat Index:</td>.*?<span class="nobr"><span class="b">([0-9\.]+)</span>#s', $page, $matches)) {
    $heat_index = $matches[1];
}

echo "$current_temp\n$heat_index\non\non\n";

?>

And add it to your MRTG config with something like this (Note that you need to specify your zip code in the ‘Target’ line):

Target[temp]: `/etc/mrtg/temperature.php 30605`
Options[temp]: nopercent,growright,nobanner,nolegend,noinfo,integer,gauge
Title[temp]: Outdoor Temperature
PageTop[temp]: <h3>Outdoor Temperature</h3>
YLegend[temp]: Degrees Farenheight
ShortLegend[temp]: &nbsp;&deg;F
LegendI[temp]: Temperature &deg;F&nbsp;
LegendO[temp]: Heat Index &deg;F&nbsp;

The PHP Curl Documentation for CURLOPT_POSTFIELDS makes this note:

This can either be passed as a urlencoded string like ‘para1=val1&para2=val2&…’ or as an array with the field name as key and field data as value. If value is an array, the Content-Type header will be set to multipart/form-data.

I’ve always discounted the importance of that, and in most cases it doesn’t generally matter. The destination server and application likely know how to deal with both multipart/form-data and application/x-www-form-urlencoded equally well. However, the data is passed in a much different way using these two different mechanisms.

application/x-www-form-urlencoded

application/x-www-form-urlencoded is what I generally think of when doing POST requests. It is the default when you submit most forms on the web. It works by appending a blank line and then your urlencoded data to the end of the POST request. It also sets the Content-Length header to the length of your data. A request submitted with application/x-www-form-urlencoded looks like this (somewhat simplified):

POST /some-form.php HTTP/1.1
Host: www.brandonchecketts.com
Content-Length: 23
Content-Type: application/x-www-form-urlencoded

name=value&name2=value2

multipart/form-data

multipart/form-data is much more complicated, but more flexible. Its flexibility is required when uploading files. It works in a manner similar to MIME types. The HTTP Request looks like this (simpified):

POST / HTTP/1.1
Host: www.brandonchecketts.com
Content-Length: 244
Expect: 100-continue
Content-Type: multipart/form-data; boundary=----------------------------26bea3301273

And then subsequent packets are sent containing the actual data. In my simple case with two name/value pairs, it looks like this:

HTTP/1.1 100 Continue
------------------------------26bea3301273
Content-Disposition: form-data; name="name"

value
------------------------------26bea3301273
Content-Disposition: form-data; name="name2"

value2
------------------------------26bea3301273--

CURL usage

So, when sending POST requests in PHP/cURL, it is important to urlencode it as a string first.

This will generate the multipart/form-data version

$data = array('name' => 'value', 'name2' => 'value2');
curl_setopt($curl_object, CURLOPT_POSTFIELDS,  $data)

And this simple change will ensure that it uses the application/x-www-form-urlencoded version:

$data = array('name' => 'value', 'name2' => 'value2');
$encoded = '';
foreach($data as $name => $value){
    $encoded .= urlencode($name).'='.urlencode($value).'&';
}
// chop off the last ampersand
$encoded = substr($encoded, 0, strlen($encoded)-1);
curl_setopt($curl_object, CURLOPT_POSTFIELDS,  $encoded)

KnitMeter.com is a site that I wrote quickly for my wife to keep track of how much she has knit. It generate a little ‘widget’ image that can be placed on blogs, forums, etc and says how many miles of yarn you have knit in some period. The site has been live for about a year and a half now and has a couple thousand registered users.

I have been receiving an increasing number of requests to add a method for adding a KnitMeter it to Facebook. I’ve experimented with a couple of other ideas on Facebook and found that it was pretty straightforward to write an app. KnitMeter seems like a decent candidate for a social app, so I started working on it about a week ago. And I’m happy to say that I just made the application live late last night. It is available at http://apps.facebook.com/knitmeter/.

Features include:

• Ability to add projects and add knitted lengths to a project (or not)
• Settings for inputting lengths in feet, yards, or meters
• Display how much you’ve knit in feet, yards, meters, kilometers, or miles
• When entering a new length, you can choose to have it publish a ’story’ on your profile page
• You can add a tab on your profile page that shows each of your projects as well as a total
• You can add a KnitMeter ‘box’ to the side of your profile page, or on your ‘boxes’ tab.

I recreated the database from scratch and defined it a little better, so I have a little bit of work to do in migrating the existing site and database over to the new structure. Once that is done users will be able to import their data from the existing KnitMeter.com by providing their email/password.

The problem: Servers in two separate geographic locations each have their own memcached cluster. However, there doesn’t currently exist (that I know of) a good way to copy data from one cluster to the other cluster.

One possible solution is to configure the application to perform all write operations in both places. However, each operation requires a round-trip response. If the servers are separated by 50ms or more, doing several write operations causes a noticable delay.

The solution that I’ve come up with is a perl program that I’m calling memcache_sync. It acts a bit like a proxy that asynchronously performs write operations on a remote cluster. Each geographic location runs an instance of memcache_sync that emulates a memcached server. You configure your application to write to the local memcache cluster, and also to the memcache_sync instance. memcache_sync queues the request and immediately returns a SUCCESS message so that your application can continue doing its thing. A separate thread then writes those queued operations to the remote cluster.

The result is two memcache clusters that are synchronized in near-real time, without any noticable delay in the application.

I’ve implemented ’set’ and ‘delete’ operations thus far, since that is all that my application uses. I’ve just started using this on a production environment and am watching to see how it holds up. So far, it is behaving well.

The script is available here. I’m interested to see how much need there is for such a program. I’d be happy to have input from others and in developing this into a more robust solution that works outside of my somewhat limited environment.

After upgrading to MySQL 5, one of my databases appeared empty even though the MyISAM tables existed in /var/lib/mysql/database-name. I found this error in the mysql log file in /var/log/mysqld.log:

090425 23:10:52 [ERROR] Invalid (old?) table or database name 'database-name'

Turns out that MySQL 5 doesn’t like database names that contain a hyphen. In the mysql directory, I see that it created a second directory for the database, but with the hyphen replaced with ‘@002d’.

drwx------  2 mysql mysql     4096 Apr 25 23:10 database-name
drwx------  2 mysql mysql     4096 Apr 24 00:30 database@002dname

To resolve that I decided to replace the hyphen with an underscore. I stopped mysql, renamed /var/lib/mysql/database-name to /var/lib/mysql/database_name, and then ran this SQL to update the permissions:

UPDATE mysql.db SET Db = 'database_name' WHERE Db = 'database\-name';
FLUSH PRIVILEGES;

I could then see the tables using mysql from the command line. From there, I just updated the setting for the application to use the new name, and everything worked out find.

When you use auto-tagging with your Adwords campaign, all request that are generated by Google Adwords contain a ?glcid parameter in the Request. Adwords uses this to pass some information to Analytics for traffic analysis.

I was curious, about what data the gclid parameter contained. My guess was that it contained some encoded or encrypted information regarding the origin of the click, so I did some analysis on the clicks that I received. Some discussion about it was available on this post.

I ended up writing a quick PHP script that parses through an Apache log file. It finds requests that contain a gclid and then produces a report of which letters occur in which positions of the gclid.

The script is available for download here, and it generates a report like this:

Found 32507 appropriate lines
Character  1 [ 1] C
Character  2 [ 8] IJKLMNOP
Character  3 [32] -CDGHKLOPSTWX_abefijmnqruvyz2367
Character  4 [64] -CDEFG0ABHIJKLMNOPQRSTUVWXYZ_abcdefghijklmnopqrstuvwxyz123456789
Character  5 [32] -_0ghijklmnopqrstuvwxyz123456789
Character  6 [32] -IJKLMNOPYZ_abcdefopqrstuv456789
Character  7 [32] -CDGHKLOPSTWX_abefijmnqruvyz2367
Character  8 [64] -ABCDEFG0HIJKLMNOPQRSTUVWXYZ_abcdefghijklmnopqrstuvwxyz123456789
Character  9 [32] 0-_ghijklmnopqrstuvwxyz123456789
Character 10 [ 4] JZp5
Character 11 [ 8] IMQUYcgk
Character 12 [ 1] C
Character 13 [ 1] F
Character 14 [10] QRSUWYZcde
Character 15 [61] -ABCEFGHIJKLMNOPQRSTUVWXYZ_ab0cdefghiklmnopqrstuvwxy123456789
Character 16 [63] -ABCDEFGHIJKLMNOQRSTUVWXYZ_abcde0fghijklmnopqrstuvwxyz123456789
Character 17 [17] DFGHIQabgiknrsx57
Character 18 [ 4] AQgw
Character 19 [ 1] o
Character 20 [ 1] d
Character 21 [64] -ABCDEFGHIJKLMNOPQRSTUVWXYZ_abcdefghijklmnopqrstuvwx0yz123456789
Character 22 [32] ABCDEFGHQRSTUVWXghijklmnwyz0x123
Character 23 [64] -ABCDEFGHIJKLMNOPQRSTUVWXYZ_abcdefghijklmnopqrstuv0wxyz123456789
Character 24 [64] -ABCDEFGHIJKLMNOPQRSTUVWXYZ_abcdefghijklmnopqrs0tuvwxyz123456789
Character 25 [62] 0-ABCDEFHIJKLMOPQRSTUVWXYZ_abcdefghijklmnopqrstuvwxyz123456789
Character 26 [ 4] AQgw

This makes it clear that the parameter has some structure, but I’m still no closer to determining what it contains. Counting up the unique values, it would seem that they have about 95 bits of information available, which might be enough room to store everything it would need to know about the search that created it. Based on the reporting details in Analytics, I would presume that it somehow contains at least the following information:

• Campaign (id)
• Keyword (id)
• Ad Variation (id)
• Position

I did some research by clicking an ad multiple times and examining the glcids for those:

        12345678901234567890123456
/?gclid=CNHz5eD_8pkCFRCdnAodzniYQg
/?gclid=CIX_u-X_8pkCFQKenAodlWprSg
/?gclid=CMyI_4OA85kCFRIhnAodc2_oRg
/?gclid=CO_0pYyA85kCFQghnAodDDpaRQ
/?gclid=CIXo9JeA85kCFRIhnAodc2_oRg
/?gclid=CLitgp2A85kCFQubnAod1nx7Qg
/?gclid=CN3_1aOA85kCFQghnAodDDpaRQ
/?gclid=CPyi1quA85kCFRabnAodWnZbRQ
/?gclid=COq-67OA85kCFRMhnAodyQvSRg
/?gclid=COOplrmA85kCFRCdnAodzniYQg

I noticed that most of the characters which use 32-64 characters vary quite a bit except for character #9, which was always an 8, and character #10 which was a ‘p’ for the first two clicks, and then a ‘5′ for all subsequent clicks. That likely has some significance, but I’m out of time for playing with it for now.

Hopefully the script and this basic analysis might be of use for somebody else to use in digging into it further.

One other thought that I had is that the data (or each field) is somehow encrypted and when you ‘link’ your Analytics account to your Adwords account it shares the decryption key so that it can get at the detail.

A fairly simple method of having postfix send messages through SpamAssassin, and then delivering the messages identified as spam to a separate mailbox:

Configure SpamAssassin as normal in master.cf:

smtp      inet  n       -       -       -       -       smtpd -o content_filter=spamassassin
2525      inet  n       -       -       -       -       smtpd -o content_filter=spamassassin
spamassassin unix -     n       n       -       -       pipe user=spamd argv=/usr/bin/spamc -f -e    /usr/sbin/sendmail -oi -f ${sender} ${recipient}

Configure Spamassassin to log the status and score in a new header by adding this to /etc/spamassassin/local.cf:

## Add a spamassassin header to all messages so that we can filter them out
add_header all Status _YESNO_, score=_SCORE_ required=_REQD_ tests=_TESTS_ autolearn=_AUTOLEARN_ version=_VERSION_

And then configure postfix to look for that header and deliver it to an alternate mailbox:

/etc/postfix/main.cf:

header_checks = regexp:/etc/postfix/header_checks

/etc/postfix/header_checks:

/^X-Spam-Status: Yes/ REDIRECT spam@yourdomain.com

Now your messages identified as spam will be sent to spam@yourdomain.com so that you can occasionally check for false positives.

Note that there is more work that goes into setting up SpamAssassin, but there are plenty of howtos around for getting that configured.

This is the coolest thing. I almost closed the video before I saw my name in it.

Here is the video

What a brilliant advertising scheme and likely the future of advertising. Somebody deserves a raise. You can obviously substitute your own name in the URL and the video will have your name in it.
